    Problem with Mad Catz Xbox 360 wired controller

    GamePad/GPIO/USB encoder
    mad catz xbos 360 wired
    3
    15
    5794
    Loading More Posts
    • Oldest to Newest
    • Newest to Oldest
    • Most Votes
    Reply
    • Reply as topic
    Log in to reply
    This topic has been deleted. Only users with topic management privileges can see it.
    • WSP77
      WSP77 last edited by WSP77

      Hi, I'm a newcomer in the forum and at recalbox, and need your help already!
      I've just bought a Mad Catz wired controller (Xbox 360), model WWE All Stars, but I could not configure it on recalbox. It is recocnized as "generic x-box usb pad" (if I am not wrong), and I'm getting two problems: a) I could not configure the RT and LT buttons (top buttons) as R2 and L2, they does not works at all; b) the menu button, configured as hot key, keeps blinking all the time.
      All other funcions are fine. I already tried to enable xbox drivers by editing the configuration file, but the controller is not recognized as a Xbos 360 controller. Any ideas to get RT and LT working and solves the blinking led? Thanks and sorry my bad english. In time: I am using Recalbox 4.0.

      1 Reply Last reply Reply Quote 0
      • acris
        acris last edited by

        Hello

        you need to enable xboxdrv driver and disable psx driver in recalbox.conf
        https://github.com/recalbox/recalbox-os/wiki/recalbox.conf-(EN)

        ## Please enable only one of these
        # -------------- D1 - PS3 Controllers ------------ #
        ##Enable PS3 controllers support
        controllers.ps3.enabled=0
        ## Choose an driver between official, shanwan and gasia if you have dualshock clones (official,shanwan,gasia)
        controllers.ps3.driver=official


        # ------------ D2 - XBOX Controllers ------------ #
        ## Xbox controllers are already supported, but xboxdrv can solve some compatibility issues
        ## Enable xboxdrv driver, disable this if you enabled ps3 controllers (0,1)
        controllers.xboxdrv.enabled=1
        ## Set the amount of controllers to use with xboxdrv (0..4)
        controllers.xboxdrv.nbcontrols=2


        reconfigure gamepad in emulationstation menu.

        1 Reply Last reply Reply Quote 0
        • WSP77
          WSP77 last edited by

          Hi! Thx for the answear. I already tried it and doesn't work. When I did it (exactly as the screen above) three controllers apearred in emulation station menu: #0 generic x-box usb pad (or something like that, #1 xbox 360 controller and # 2 xbox 360 controller. My Mad catz is recognized as #0 generic x-box usb pad, not as a xbox 360 controller... I think I need to find a way to configure the "generic x-box usb pad driver", but I don't have any idea on how to do it.

          1 Reply Last reply Reply Quote 0
          • WSP77
            WSP77 last edited by

            No one tried to plug a Xbox 360 fight pad before me? I did some search and could not find any clue...

            1 Reply Last reply Reply Quote 0
            • acris
              acris last edited by

              Hello @WSP77
              do you have 3 gamepad xbox ?

              1 Reply Last reply Reply Quote 0
              • WSP77
                WSP77 last edited by

                No, just the Mad Catz. Let me explain: first I turned on recalbox, with no controller or anything conected at all; after I edited the recalbox.conf with NotePad++ (by pc wifi) and restart the recalbox; after restart I pluged the Mad Catz Xbox fight pad and when I get to controller configuration on emulation station there where 3 controllers there (#0, #1 and #3 as I listed berfore), but the only controller connected is the fight pad, recognized as #0 generic x-box usb pad. The pad is not recognized as a xbox 360 controller, because that I get three controllers in list, I presume...

                1 Reply Last reply Reply Quote 0
                • WSP77
                  WSP77 last edited by

                  In time, my problem is the same as it: https://forum.recalbox.com/topic/3865/xbox-360-mad-catz-wwe-all-stars-brawl-pad
                  No solution there yet...

                  1 Reply Last reply Reply Quote 0
                  • WSP77
                    WSP77 last edited by

                    No clue at all? 😞

                    Substring 1 Reply Last reply Reply Quote 0
                    • Substring
                      Substring @WSP77 last edited by

                      @WSP77 and changing controllers.xboxdrv.nbcontrols=2 to 1 ?

                      Former dev - Please reply with @substring so that i am notified when you answer me
                      Ex dev - Merci de me répondre en utilisant @substring pour que je sois notifé

                      1 Reply Last reply Reply Quote 0
                      • WSP77
                        WSP77 last edited by

                        I'll try that. And I'll post a picture of the emulation station configuration screen and of my config file too. Thx for the answear!

                        Substring 1 Reply Last reply Reply Quote 0
                        • Substring
                          Substring @WSP77 last edited by

                          @WSP77 well, i guess it won't help : your pad is configured by the xpad driver, and unknown to xboxdrv ... We could make it work with xboxdrv but it's a little complicated :

                          • requires you blacklist xpad
                          • create a dedicated conf file for xboxdrv
                          • add it to the start process

                          Former dev - Please reply with @substring so that i am notified when you answer me
                          Ex dev - Merci de me répondre en utilisant @substring pour que je sois notifé

                          1 Reply Last reply Reply Quote 0
                          • WSP77
                            WSP77 last edited by

                            Well, I tried and got no success. By disabling PS3 (0) controllers and enabling xboxdrv (1 and 1) I got 2 controllers identified by emulation station: #0 Generic X-box pad and # 1 Xbox Gamepad (US...IVER).
                            The Ma Catz fight pad is just recognized as #0, and I could not make LT and RT works... I think this is end of the line for me...

                            1 Reply Last reply Reply Quote 0
                            • WSP77
                              WSP77 last edited by

                              This is a screen of the pad, anyone got one of this model to work on Recalbox?
                              alt text

                              Substring 1 Reply Last reply Reply Quote 0
                              • Substring
                                Substring @WSP77 last edited by

                                @WSP77 maybe this will be solved once rockaddicted updates the xpad driver on recalbox 4.1

                                Former dev - Please reply with @substring so that i am notified when you answer me
                                Ex dev - Merci de me répondre en utilisant @substring pour que je sois notifé

                                1 Reply Last reply Reply Quote 0
                                • WSP77
                                  WSP77 last edited by

                                  I will wait then, to be honest I bought this joypad just to play arcade and Mega Drive games properly on Recallbox. ^^

                                  1 Reply Last reply Reply Quote 0
