    Original N64 Controller/MayFlash/Adapter Joystick keine Funktion!

    Controller/GPIO/USB
    original joystick keine funktion
    4
    18
    5628
    Loading More Posts
    • Oldest to Newest
    • Newest to Oldest
    • Most Votes
    Reply
    • Reply as topic
    Log in to reply
    This topic has been deleted. Only users with topic management privileges can see it.
    • JumpingJack88
      JumpingJack88 @acris last edited by

      @acris

      I heard that the nes and snes work great on recalbox!

      cmdline.text =
      dwc_otg.fiq_fix_enable=1 sdhci-bcm2708.sync_after_dma=0 dwc_otg.lpm_enable=0 console=tty3 loglevel=3 elevator=deadline vt.global_cursor_default=0 logo.nologo root=/dev/mmcblk0p7 rootwait fastboot noswap ro usbhid.quirks=0xe8f:0x3013:0x040

      archiev = http://www37.zippyshare.com/v/298NKtYy/file.html

      Thx for dont give up!

      JumpingJack88

      1 Reply Last reply Reply Quote 0
      • ian57
        ian57 Staff last edited by

        as the dmesg command answer, the controller is well detected :

        [    2.328286] usb 1-1.4: new low-speed USB device number 5 using dwc_otg
        [    2.502000] usb 1-1.4: New USB device found, idVendor=0e8f, idProduct=3013
        [    2.502021] usb 1-1.4: New USB device strings: Mfr=1, Product=2, SerialNumber=0
        [    2.502028] usb 1-1.4: Product: USB GamePad
        [    2.502034] usb 1-1.4: Manufacturer: HuiJia
        [    2.614471] input: HuiJia  USB GamePad as /devices/platform/soc/3f980000.usb/usb1/1-1/1-1.4/1-1.4:1.0/0003:0E8F:3013.0004/input/input2
        [    2.614681] input: HuiJia  USB GamePad as /devices/platform/soc/3f980000.usb/usb1/1-1/1-1.4/1-1.4:1.0/0003:0E8F:3013.0004/input/input3
        [    2.614810] input: HuiJia  USB GamePad as /devices/platform/soc/3f980000.usb/usb1/1-1/1-1.4/1-1.4:1.0/0003:0E8F:3013.0004/input/input4
        [    2.614942] input: HuiJia  USB GamePad as /devices/platform/soc/3f980000.usb/usb1/1-1/1-1.4/1-1.4:1.0/0003:0E8F:3013.0004/input/input5
        [    2.615149] hid-generic 0003:0E8F:3013.0004: input,hidraw3: USB HID v1.10 Joystick [HuiJia  USB GamePad] on usb-3f980000.usb-1.4/input0


        so, you'll need to test it with the evtest or jstest under ssh connnection program, to check if the joystick is working or if it is juste a configuration problem

        # evtest
        No device specified, trying to scan all of /dev/input/event*
        Available devices:
        /dev/input/event0:	DragonRise Inc.   Generic   USB  Joystick
        Select the device event number [0-0]: 0


        for example

        But first if you have other usb devices connected to the Rpi 😉 , recheck with only your gamepad connected.

        iManufacturer           1 Logitech
          iProduct                2 USB Receiver


        "UNIX is basically a simple operating system, but you have to be a genius to understand the simplicity." Dennis Ritchie

        JumpingJack88 1 Reply Last reply Reply Quote 0
        • JumpingJack88
          JumpingJack88 @ian57 last edited by

          @ian57

          evtest

          No device specified, trying to scan all of /dev/input/event*
          Available devices:
          /dev/input/event0: Logitech USB Receiver
          /dev/input/event1: Logitech USB Receiver
          /dev/input/event2: HuiJia USB GamePad
          /dev/input/event3: HuiJia USB GamePad
          /dev/input/event4: HuiJia USB GamePad
          /dev/input/event5: HuiJia USB GamePad
          Select the device event number [0-5]:

          select: 2

          moving joystick up =

          Testing ... (interrupt to exit)
          Event: time 1479143920.295353, type 3 (EV_ABS), code 1 (ABS_Y), value 126
          Event: time 1479143920.295353, -------------- SYN_REPORT ------------
          Event: time 1479143920.311368, type 3 (EV_ABS), code 1 (ABS_Y), value 124
          Event: time 1479143920.311368, -------------- SYN_REPORT ------------
          Event: time 1479143920.327356, type 3 (EV_ABS), code 1 (ABS_Y), value 123
          Event: time 1479143920.327356, -------------- SYN_REPORT ------------
          Event: time 1479143920.343332, type 3 (EV_ABS), code 1 (ABS_Y), value 119
          Event: time 1479143920.343332, -------------- SYN_REPORT ------------
          Event: time 1479143920.359323, type 3 (EV_ABS), code 1 (ABS_Y), value 110
          Event: time 1479143920.359323, -------------- SYN_REPORT ------------
          Event: time 1479143920.375325, type 3 (EV_ABS), code 1 (ABS_Y), value 99
          Event: time 1479143920.375325, -------------- SYN_REPORT ------------
          Event: time 1479143920.391325, type 3 (EV_ABS), code 1 (ABS_Y), value 89
          Event: time 1479143920.391325, -------------- SYN_REPORT ------------
          Event: time 1479143920.407327, type 3 (EV_ABS), code 1 (ABS_Y), value 80
          Event: time 1479143920.407327, -------------- SYN_REPORT ------------
          Event: time 1479143920.423354, type 3 (EV_ABS), code 1 (ABS_Y), value 72
          Event: time 1479143920.423354, -------------- SYN_REPORT ------------
          Event: time 1479143920.439340, type 3 (EV_ABS), code 1 (ABS_Y), value 63
          Event: time 1479143920.439340, -------------- SYN_REPORT ------------
          Event: time 1479143920.455342, type 3 (EV_ABS), code 1 (ABS_Y), value 59
          Event: time 1479143920.455342, -------------- SYN_REPORT ------------
          Event: time 1479143920.471341, type 3 (EV_ABS), code 1 (ABS_Y), value 57
          Event: time 1479143920.471341, -------------- SYN_REPORT ------------
          Event: time 1479143920.487346, type 3 (EV_ABS), code 0 (ABS_X), value 129
          Event: time 1479143920.487346, type 3 (EV_ABS), code 1 (ABS_Y), value 55
          Event: time 1479143920.487346, -------------- SYN_REPORT ------------
          Event: time 1479143920.583379, type 3 (EV_ABS), code 1 (ABS_Y), value 59
          Event: time 1479143920.583379, -------------- SYN_REPORT ------------
          Event: time 1479143920.599411, type 3 (EV_ABS), code 0 (ABS_X), value 127

          If i hold the joystick it stops on this point

          so i think the has detected teh joystick!
          but i'am a noob un raspberry and linux

          hope you cam help me to solve my problem

          1 Reply Last reply Reply Quote 0
          • acris
            acris last edited by

            Hello @JumpingJack88

            Do you map your controller in Emulationstation Menu > Options gamepad ?
            You need to map, D-pad on D-pad and Analogy Control stick on joystick.

            text alternatif

            JumpingJack88 1 Reply Last reply Reply Quote 0
            • JumpingJack88
              JumpingJack88 @acris last edited by

              @acris

              yes i tried to..... but he dosn't accept any movement of the joystick!

              don't be mad for saying that but,
              i know the difference between D-Pad and Joystick 😉
              Did you find something wrong in my archive?
              do you know if there's an option too konfigurate the controller directly in system (blackscreen) of Recalbox?

              thanks for all of your help

              I hope you will find something to fix my problem

              1 Reply Last reply Reply Quote 0
              • acris
                acris last edited by acris

                @Substring do you have an idea ?

                1 Reply Last reply Reply Quote 0
                • Substring
                  Substring last edited by

                  evtest shows 2 axis. If they don't work, might require another qurik ...

                  @JumpingJack88 you should try running evtest for each huija controller and see if one gets answers from the stick

                  Former dev - Please reply with @substring so that i am notified when you answer me
                  Ex dev - Merci de me répondre en utilisant @substring pour que je sois notifé

                  JumpingJack88 1 Reply Last reply Reply Quote 0
                  • JumpingJack88
                    JumpingJack88 @Substring last edited by

                    @Substring

                    what does "quirk" mean?
                    I'm sorry but i dont now this word 😞
                    I have only one huija controller!
                    I thought it was normal that he shows me one of each free usbport!
                    There are only two devices pluged, my Logitech Keybord and a MayFlash-adapter with one Original N64 Controller!

                    1 Reply Last reply Reply Quote 0
                    • acris
                      acris last edited by

                      Hello @JumpingJack88
                      quick is a word for usbhid quick -> (usbhid.quirks=0xe8f:0x3013:0x040) .
                      This technic seems not to work with your mayflash controller.

                      But try to edit /recalbox/share/system/recalbox.conf
                      https://github.com/recalbox/recalbox-os/wiki/recalbox.conf-(DE)

                      And change inputdriver

                      ## Set retroarch input driver (auto, udev, sdl2)
                      ## If you don't have issues with your controllers, let auto
                      global.inputdriver=udev`


                      save and reboot

                      JumpingJack88 1 Reply Last reply Reply Quote 0
                      • JumpingJack88
                        JumpingJack88 @acris last edited by

                        @acris

                        thanks i'll try as soon as i can

                        1 Reply Last reply Reply Quote 0
